N7 Mobile Terminal

Product specifications

Dimension
200×70×24mm
Weight
380g
Sealing
IP65
Network Connection
WLAN, WWAN
Operating System
Android 13
Screen Size
4.0"

Features

1D Barcode
2D Barcode
IP65
Android
GPS
4G
WiFi

Vertical

Warehouse
Transportation & Logistic

Features
Specifications
Downloads
Accessories

Features

Great performance under cold storage

No fogging or frosting at all even under the situation of keeping entering and exiting the cold storage frequently, making fast and smooth scanning; 5100mAh battery designed for cold storage specially,working well under low temperature-30℃;Support Lens Heating function and can be used in both freezing and refrigerated environments.

High accuracy medium range identification

Using international top class 1D laser scan engine and2D CMOS scan engine;Support medium far distancescanning; Using 25°perfect scanning angel, makescanning more accurate;13megapixel camera, highdynamic LED light, easy to capture clear photos at any time and any place.

Excellent grip, rugged and durable

Specially designed for logistics, warehouse and other industry fields, custom 29 buttons layout. Combined with ergonomic pistol grip designing. IP65 protection grade, withstand 1.8m free drop to concrete (2 times at each surface) and work normally in pouring water situation with gloved fingers.

Type-C port and WIFI ac band

Using the mainstream Type-C fast charging port, the charging power is up to 15W, can fully charge the 5100mAh battery within 3 hours. Support 802.11acb and and WIFI 5G band, faster transmission rate and better support for WIFI roaming.

Megapixel Barcode Scanning-Duo Near & Far

Newland’s Duo Near & Far combines two 2D scan engines working side by side to select and decode barcodes at both near and far distances. By using two separate scan engines, the N7 can seamlessly switch between them based on the distance of the barcode, resulting in faster scanning and improved productivity.

Specifications

Performance	Processor	2.0GHz, octa cores 64-bit processor
	Operating System	Android 11/13
	Memory	4GB RAM, 64GB ROM
	Interface	Type-C port

Physical	Dimensions	200×70 (pistol grip 58) ×24 (battery29) mm
	Weight	380g (including battery)
	Display	4.0" WVGA IPS screen, visible under strong light, resolution 480×800
	Keypad	29/47 physical buttons, with back light function
	Virtual Button	Support three virtual buttons
	Notification	Vibrator, speaker and multi-color LEDs
	Battery	5100mAh, support battery hot-swap
	Camera	13MP, auto focus, with LED flashlight
	GPS	GPS/A-GPS/BeiDou/GLONASS/Galileo
	Expansion	Micro SD/TF card (max. 128GB)
	Sensor	Gravity sensor, hall switch
	AC Adapter	Output: Type-C 5V/2A,9V/2A,12V/1.5A， Input: AC 100~240V,50~60Hz
	Lens Heating	Support using in both freezing and refrigerated environments Optional Features(when N7 is used in both freezing and refrigerated environments)

Environmental	Operating Temperature	-20℃ to 50℃ (-4°F to 122°F)
	Storage Temperature	-40℃ to 70℃ (-40°F to 158°F)
	Humidity	5% to 95% (non-condensing)
	Static Discharge	±15 kV (Air discharge), ±8 kV (Direct discharge)
	Drop	1.8m drops to concrete (for six sides, two drops per side)
	Sealing	IP65

Barcode Scanning

2D Barcode CMOS (≥ 5 mil)

1D: Code128, UCC/EAN-128, AIM-128, EAN-8, JAN-8, EAN-3, ISBN/ISSN, UPC-E, UPC-A, Interleave2/5, ITF-6, ITF-14, Deutsche14 ,Deutsche12, COOP25, Matrix2/5, Industrial2/5, Standard25, Code39, Codabar/NW7, Code93, Code 11, Plessey, MSI/Plessey, GS1 Databar etc.
2D: PDF-417, QR Code, Data Matrix, Chinese sensible code etc.

Depth of Field

Depends on Barcode Type and Environment

Code39(5mil): 80mm-350mm; Code39(10mil) 50mm-575mm;
Code128(3mil): 100mm-180mm; Code128(10mil): 60mm-480mm;
EAN-13(13mil): 40mm-480mm; DM(15mil): 55mm-355mm;
PDF417(10mil): 60mm-320mm; QR(15mil): 50mm-400mm;

Near&Far Version:
Code128(10mil): 20-140cm;
Code128(55mil): 40-430cm;
Code128(100mil): 50-600cm;
QR(55mil): 25-300cm;
EAN13(13mil): 20-180cm

NFC

13.56MHz RFID

13.56MHz ISO14443A/B, MIFARE, FeliCa, NFC Forum Tags, ISO15693

Wireless	WLAN RADIO	Bands: built-in 802.11 a/b/g/n/ac, compatible with 11 d/h/i/k/r/v/w, support 2.4G and 5G dual frequency Roaming: Support Fast Roaming
	WWAN RADIO	2G: GSM: 850/900/1800/1900MHz 3G: WCDMA: B1/B2/B5/B8 TD-SCDMA: B34/B39 CDMA 1x/EVDO: BC0 4G: FDD-LTE:B1/B2/B3/B5/B7/B8/B20/B28a&b TDD-LTE:B38/B39/B40/B41
	WPAN RADIO	Dual mode, BT5.0+LE(Backward-compatible)

Card Slots

SIM Card.

Nano+Nano or Nano+TF

Accessory

AC adapter, cable, charging cradle, hand strap, 4-slot charger

Performance

Processor
2.0GHz, octa cores 64-bit processor

Operating System
Android 11/13

Memory
4GB RAM, 64GB ROM

Interface
Type-C port

Physical

Dimensions
200×70 (pistol grip 58) ×24 (battery29) mm

Weight
380g (including battery)

Display
4.0" WVGA IPS screen, visible under strong light, resolution 480×800

Keypad
29/47 physical buttons, with back light function

Virtual Button
Support three virtual buttons

Notification
Vibrator, speaker and multi-color LEDs

Battery
5100mAh, support battery hot-swap

Camera
13MP, auto focus, with LED flashlight

GPS
GPS/A-GPS/BeiDou/GLONASS/Galileo

Expansion
Micro SD/TF card (max. 128GB)

Sensor
Gravity sensor, hall switch

AC Adapter
Output: Type-C 5V/2A,9V/2A,12V/1.5A， Input: AC 100~240V,50~60Hz

Lens Heating
Support using in both freezing and refrigerated environments Optional Features(when N7 is used in both freezing and refrigerated environments)

Environmental

Operating Temperature
-20℃ to 50℃ (-4°F to 122°F)

Storage Temperature
-40℃ to 70℃ (-40°F to 158°F)

Humidity
5% to 95% (non-condensing)

Static Discharge
±15 kV (Air discharge), ±8 kV (Direct discharge)

Drop
1.8m drops to concrete (for six sides, two drops per side)

Sealing
IP65

Barcode Scanning

2D Barcode CMOS (≥ 5 mil)
1D: Code128, UCC/EAN-128, AIM-128, EAN-8, JAN-8, EAN-3, ISBN/ISSN, UPC-E, UPC-A, Interleave2/5, ITF-6, ITF-14, Deutsche14 ,Deutsche12, COOP25, Matrix2/5, Industrial2/5, Standard25, Code39, Codabar/NW7, Code93, Code 11, Plessey, MSI/Plessey, GS1 Databar etc. 2D: PDF-417, QR Code, Data Matrix, Chinese sensible code etc.

Depth of Field

Depends on Barcode Type and Environment
Code39(5mil): 80mm-350mm; Code39(10mil) 50mm-575mm; Code128(3mil): 100mm-180mm; Code128(10mil): 60mm-480mm; EAN-13(13mil): 40mm-480mm; DM(15mil): 55mm-355mm; PDF417(10mil): 60mm-320mm; QR(15mil): 50mm-400mm; Near&Far Version: Code128(10mil): 20-140cm; Code128(55mil): 40-430cm; Code128(100mil): 50-600cm; QR(55mil): 25-300cm; EAN13(13mil): 20-180cm

NFC

13.56MHz RFID
13.56MHz ISO14443A/B, MIFARE, FeliCa, NFC Forum Tags, ISO15693

Wireless

WLAN RADIO
Bands: built-in 802.11 a/b/g/n/ac, compatible with 11 d/h/i/k/r/v/w, support 2.4G and 5G dual frequency Roaming: Support Fast Roaming

WWAN RADIO
2G: GSM: 850/900/1800/1900MHz 3G: WCDMA: B1/B2/B5/B8 TD-SCDMA: B34/B39 CDMA 1x/EVDO: BC0 4G: FDD-LTE:B1/B2/B3/B5/B7/B8/B20/B28a&b TDD-LTE:B38/B39/B40/B41

WPAN RADIO
Dual mode, BT5.0+LE(Backward-compatible)

Card Slots

SIM Card.
Nano+Nano or Nano+TF

Accessory

Accessory
AC adapter, cable, charging cradle, hand strap, 4-slot charger
